Lichtleiste LED-MLL 41.4.OP IP40 31-41W/4800-6000lm/4000K/CRI>80 1490x35x58 mm/AL elox./Abd.opal

Datenblatt_LED_Lichtleiste___MLL_einstellbar__de_en_2025_10.pdf Montageanleitung_LED_Lichtleiste___MLL___de_en__2025_09.pdf

MLL - Lichtleiste mit opaler Abdeckung

Length: 1490 mm, Colour temperature: 4000 K, Max. system power: 41 W, Rated luminous flux according to IEC 62722-2- 1: 6000 lm

Product nr.: 3382220

See all versions

Length

Max. system power

Rated luminous flux according to IEC 62722-2- 1

Price for registered users only

As a registered user, you have access to all prices for our items and can order directly.

Product description

> Elegante und vielseitige Aluminiumleuchte
> Gehäuse aus eloxiertem Aluminium – robust, leicht und formstabil
> Opale Abdeckung sorgt für eine homogene Lichtverteilung
> MULTI-WATT Ausführung zur flexiblen Leistungsanpassung
> EIN/AUS-Schalter optional integrierbar
> In 3 Längen verfügbar (600 mm, 1.200 mm, 1.500 mm)

Special features

Surface-mounted luminaire

Connected loads 100-240 V, 50-60 Hz

Color-Rendering-Index CRI-80

Lifespan 50000-L80

LED

Risk group RG-0

Color Consistency SDCM-3

Sconce

Technical specifications

General

ETIM-class:

Ceiling-/wall luminaire

Housing material:

Aluminium

Surface protection housing:

Anodised

Housing colour:

Silver

Material cover:

Plastic, opal

Voltage type:

Type of control gear:

LED operating device current-controlled

Light distributor:

Diffuser lens/optic/panel

Light distribution:

Symmetric

Beam angle:

> 80° - Extreme wide beam

Colour consistency (McAdam ellipse):

SDCM3

Light outlet:

Direct

Degree of protection (IP), rear side:

IP40

Degree of protection (IP), front side:

IP40

Impact strength:

IK03

Protection class according to IEC 61140:

Filament test according to IEC 60695-2-11:

650 °C - 30 s

Colour rendering index CRI:

80-89

Type of wiring:

Suitable for loop-through wiring

Connection type:

Push-in clamp

Photobiological safety according to EN 62471:

RG0

Colour of light adjustable:

Luminous flux adjustable:

Positions

Beam angle adjustable:

Colour temperature:

4000 K

Rated lifetime L70/B50 at 25 °C:

50000 h

Length:

1490 mm

Rated luminous flux according to IEC 62722-2- 1:

6000 lm

Max. system power:

41 W

Width:

35 mm

Height/depth:

58 mm

Downloads

Datenblatt_LED_Lichtleiste___MLL_einstellbar__de_en_2025_10.pdf Montageanleitung_LED_Lichtleiste___MLL___de_en__2025_09.pdf

All versions

Type	Colour temperature	Length	Rated luminous flux according to IEC 62722-2- 1	Max. system power	Product nr.
Type Lichtleiste LED-MLL 13.4.OP IP40 8-13W/1200-2000lm/4000K/CRI>80 590x35x58 mm/AL elox./Abd.opal	Colour temperature 4000 K	Length 590 mm	Rated luminous flux according to IEC 62722-2- 1 2000 lm	Max. system power 13 W	Product nr. 3382200
Lichtleiste LED-MLL 13.4.OP IP40 8-13W/1200-2000lm/4000K/CRI>80 590x35x58 mm/AL elox./Abd.opal Length: 590 mm, Colour temperature: 4000 K, Max. system power: 13 W, Rated luminous flux according to IEC 62722-2- 1: 2000 lm Product-Nr.: 3382200 Length: 590 mm Colour temperature: 4000 K Max. system power: 13 W Rated luminous flux according to IEC 62722-2- 1: 2000 lm Price only for registered users Log in To product

Type Lichtleiste LED-MLL 41.4.OP IP40 31-41W/4800-6000lm/4000K/CRI>80 1490x35x58 mm/AL elox./Abd.opal	Colour temperature 4000 K	Length 1490 mm	Rated luminous flux according to IEC 62722-2- 1 6000 lm	Max. system power 41 W	Product nr. 3382220
Lichtleiste LED-MLL 41.4.OP IP40 31-41W/4800-6000lm/4000K/CRI>80 1490x35x58 mm/AL elox./Abd.opal Length: 1490 mm, Colour temperature: 4000 K, Max. system power: 41 W, Rated luminous flux according to IEC 62722-2- 1: 6000 lm Product-Nr.: 3382220 Length: 1490 mm Colour temperature: 4000 K Max. system power: 41 W Rated luminous flux according to IEC 62722-2- 1: 6000 lm Price only for registered users Log in To product

Type Lichtleiste LED-MLL 27.4.OP IP40 17-27W/2500-4000lm/4000K/CRI>80 1190x35x58 mm/AL elox./Abd.opal	Colour temperature 4000 K	Length 1190 mm	Rated luminous flux according to IEC 62722-2- 1 4000 lm	Max. system power 27 W	Product nr. 3382210
Lichtleiste LED-MLL 27.4.OP IP40 17-27W/2500-4000lm/4000K/CRI>80 1190x35x58 mm/AL elox./Abd.opal Length: 1190 mm, Colour temperature: 4000 K, Max. system power: 27 W, Rated luminous flux according to IEC 62722-2- 1: 4000 lm Product-Nr.: 3382210 Length: 1190 mm Colour temperature: 4000 K Max. system power: 27 W Rated luminous flux according to IEC 62722-2- 1: 4000 lm Price only for registered users Log in To product
